Hebei Xinjuyuan Protective Net Engineering Co., Ltd. is one of the most experienced manufacturers and suppliers of military sand barrier in China. With abundant experience, we warmly welcome you to buy cost-efficient military sand barrier for sale here from our factory. Good service and reasonable price are available.
Products Description
Military sand barrier is a military defense wall that can block simple external attacks. It has the characteristics of convenience, speed, simplicity and good defense. It can also be set up with guard towers, bunkers, temporary ammunition depots and other facilities.
Equipment used for perimeter security and defense walls, equipment revetments, and search areas for explosives and contraband.
Military sand barrier, also known as explosion-proof wall, has the ability to resist explosion shock waves and can limit the destructive effects of explosions to a certain range. Compared with reinforced concrete explosion-proof wall, it has the advantages of light weight, easy loading and unloading, and recyclable reuse.
Military sand barrier can be widely used in perimeter security and defense walls, equipment revetments, search areas for explosives and contraband, ammunition compounds, personnel and material bunkers, observation points, defensive shooting positions, highway checkpoints, and border checkpoints.
Protect existing structures, highway traffic management, flood control, river channels, emergency flood control deployment, erosion control retaining walls.
Features
Easy to handle and install
High strength and impact resistance
Long life, normal use
Can be filled with sand, cement, stone, soil.
1. Explosion-proof walls should be made of non-combustible materials and should not be used as load-bearing walls. Their fire resistance should not be less than 4h.
2. Explosion-proof walls can be reinforced brick walls. When there are more production personnel in the adjacent rooms or the equipment is more expensive, cast-in-place reinforced concrete walls should be used.
3. The thickness of reinforced brick walls should be determined by structural calculations, but should not be less than 240mm. The brick strength should not be less than MU7.5, and the mortar strength should not be less than M 5.
Structural reinforcement: 3Φ6-10 full-length horizontal steel bars are arranged every 500mm along the height direction of the wall, and both ends should be tied or welded with reinforced concrete frames or bent columns with embedded reinforcing bars. When the length and height of the brick wall are greater than 6m, reinforced concrete intermediate columns and beams should be provided, and structural reinforcement should be provided. The concrete strength grade should not be lower than C15, and its ends should be connected to the roof beams and frames and columns; the thickness of the reinforced concrete explosion-proof wall should not be less than 180mm, the concrete strength grade should not be less than C20, and the cross-sectional area of the steel bars is determined by structural calculations; it is not advisable to open holes on the explosion-proof wall. When process pipelines, cables, etc. must pass through, the holes should not be larger than Φ200mm, reinforcing steel bars should be arranged around the holes, and the holes should be filled and sealed tightly.
Reinforced concrete explosion-proof wall, steel plate explosion-proof wall, steel explosion-proof wall, brick explosion-proof wall, flame-retardant explosion-proof wall, military-specific explosion-proof wall.
The steel bars of the reinforced concrete explosion-proof wall are firmly tied at the intersection, and the wall thickness is usually 30 to 40cm; the depth of the thickened wall foundation buried underground should be greater than 1m. The explosion-proof wall should be able to withstand an impact pressure of 3MPa. Explosion-proof walls or other blocking facilities should be set between devices with explosion hazards and devices without explosion hazards, and around equipment with greater risks.
